200CM 380V Artdoor RM-1220S-3D/Y3G Heated Air Curtain Three Phase Remote Controlled Door Air Barrier
The Artdoor RM-1220S-3D/Y3G heated air curtain (200CM, 380V) is designed for extra-wide commercial and industrial entrances requiring maximum airflow coverage and heating performance.
Its three-phase (380V) system provides stable and continuous operation, making it suitable for heavy-duty environments such as warehouses, supermarkets, and large facilities.
The unit creates a powerful air barrier, effectively separating indoor and outdoor environments while reducing heat loss and preventing dust, insects, and external airflow.
With its 200CM width, it delivers full coverage for large door openings and high-traffic areas.
Technical Specifications
- Brand: Artdoor
- Model: RM-1220S-3D/Y3G
- Width: 200 cm
- Voltage: 380V (Three Phase)
- Motor Power: ~330–350W
- Type: Heated Air Curtain
- Heating System: Electric (PTC type)
- Installation: Wall mounted (above door)
- Application: Industrial and commercial entrances
- Function: Air separation, temperature control, energy saving
Important Note
- Manufacturer page includes R-410A reference
- This model operates as an air curtain (fan + electric heater)
- It does not function as a refrigerant-based cooling system
Advantages & Disadvantages
Advantages
- Extra-wide coverage (200CM)
- Strong airflow barrier performance
- Stable operation with 380V three-phase system
- Suitable for industrial use
- Helps reduce energy loss
Disadvantages
- Requires 380V electrical infrastructure
- Higher energy consumption
- Installation must be done correctly
